Chicago Pneumatic CP864 Air Sander Repair Parts


Index
No.
Part No. Description No.
Req'd
1 KF129003 Bushing - Reducing 1
3 A088212 Throttle Valve Spring 1
5 KF124233 Valve - Throttle 1
6 KF124235 Stem - Throttle Valve 1
7 P083071 O-Ring (-011) 2
8 A082777 O-Ring (-12) 1
9 KF124261 Body - Throttle Valve 1
13 KF124262 Nut - Hex 1
14 KF140612 Lever - Lockoff (Comp.) 1
15 KF124264 Screw - Hinge 1
17 KF124265 Bracket - Mounting 1
18 P006600 Lockwasher (5/16") 1
19 KF124267 Nut - Hex 1
22 S082840 Ring - Retaining 1
23 C079489 O-Ring (-008) 2
25 KF129006 Valve - Speed Regulator 1
31 KF129004 Cover - Handle (Shrink Tubing) 1
32 KF124275 Housing - Motor
(Incl Index No: 31)
1
42 KF129007 Cover - Housing 1
43 KF127279 Spacer 1
54 S025055 Bearing - Ball 2
56 KF124279 Ring - Retaining 1
58 KF124280 Plate - End 2
59 KF124281 Dowel - Liner 1
60 KF124282 Liner (Incl Index No: 59) 1
61 KF124283 Body - Rotor 1
62 KF138241 Blade - Set 1
63 KF127281 Shaft - Rotor 1
70 KF124286 Key - Rotor 1
95 P091352 Screw - Cap (8-32 x 1) 1
96 KF127299 Hub - Orbital 1
97 KF127298 Lock - Spindle 1
99 C065376 Screw - Cap (1/4-20 x 1-1/4) 1
100 KF124291 Washer - Flat 1
102 KF124293 Washer - Spring 1
103 CA048099 Flexloc Hex Nut 1
104 KF139516 Spindle 1
106 KF137768 Ring - Retaining 1
113 KF124296 Housing - Drive 1
118 KF124297 Gasket - Housing 1
119 KF124298 Screw - Cap (10-24 x 1-1/2) 2
120 C078984 Screw - Cap (10-24 x 5/8) 2
123 KF125347 Washer - Spring 1
124 KF140658 Pad - Sanding (Not Shown) 1
141 CA146619 Decal - Safety Warning 1
142 C146046 Label - Rotation 1
Tune-Up Kit KF132237 Incl Index Nos: 5, 7, 8, 23, 56, 62 & 118
Sort By:
MIL1001-4 Milton Industries Tool Oil 4oz. Flip Top 1001-4 Milton Industries Tool Oil 4oz. Flip Top

Extends life and performance of air tools, lubricators, valves and cylinders. Prevents seizure of air tools and pneumatic equipment. Recommended for tools requiring a 10 weight non-detergent lubricant. Working temperature: 5 F to 350 F.

Price $5.15
2050487813 Chicago Pneumatic Throttle Valve & Spring 2050487813 Chicago Pneumatic Throttle Valve & Spring

2050487813 Chicago Pneumatic Throttle Valve & Spring

Discontinued
8940158455 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease 100Gm Tube 8940158455 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease 100Gm Tube

8940158455 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease 100Gm Tube

Price $29.28
8940158456 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease Cartridge 8940158456 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease Cartridge

8940158456 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease Cartridge

Price $36.54
A082777 Chicago Pneumatic O-Ring In-012 A082777 Chicago Pneumatic O-Ring In-012

A082777 Chicago Pneumatic O-Ring In-012

Price $7.10
A088212 Chicago Pneumatic Throttle Valve Spring A088212 Chicago Pneumatic Throttle Valve Spring

A088212 Chicago Pneumatic Throttle Valve Spring

Discontinued
C065376 Chicago Pneumatic Screw-Soc Cap 1/4"-2 C065376 Chicago Pneumatic Screw-Soc Cap 1/4"-2

C065376 Chicago Pneumatic Screw-Soc Cap 1/4"-2

Price $3.92
C078984 Chicago Pneumatic Socket Hd Screw C078984 Chicago Pneumatic Socket Hd Screw

C078984 Chicago Pneumatic Socket Hd Screw

Price $3.87
C079489 Chicago Pneumatic O-Ring In-008 C079489 Chicago Pneumatic O-Ring In-008

C079489 Chicago Pneumatic O-Ring In-008

Price $8.64
C098689 Chicago Pneumatic Push-Type Hand Grease Gun For Flush Fittings C098689 Chicago Pneumatic Push-Type Hand Grease Gun For Flush Fittings

C098689 Chicago Pneumatic Push-Type Hand Grease Gun For Flush Fittings

Price $15.61
CA000046 Chicago Pneumatic Air Tool Oil Protecto Lube 20 Oz. CA000046 Chicago Pneumatic Air Tool Oil Protecto Lube 20 Oz.

CA000046 Chicago Pneumatic Air Tool Oil Protecto Lube 20 Oz. 20 oz. Top-grade product is expertly made in compliance with stringent industry standards to offer a fusion of a well-balanced design and high level of craftsmanship.

Price $8.76
CA048099 Chicago Pneumatic Flexloc Hex Nut CA048099 Chicago Pneumatic Flexloc Hex Nut

CA048099 Chicago Pneumatic Flexloc Hex Nut

Discontinued
CA146619 Chicago Pneumatic Decal-Safety Warning CA146619 Chicago Pneumatic Decal-Safety Warning

CA146619 Chicago Pneumatic Decal-Safety Warning

Price $3.89
CA149661 Chicago Pneumatic Oil Protecto Lube 4 Oz. CA149661 Chicago Pneumatic Oil Protecto Lube 4 Oz.

CA149661 Chicago Pneumatic Oil Protecto Lube 4 Oz.

Price $4.86
CP7269S Chicago Pneumatic 7" Angle Sander CP7269S Chicago Pneumatic 7" Angle Sander

CP7269S 7" Angle Sander - This 7" heavy-duty angle sander has a rugged 0.7 horse power motor, ground spiral bevel gears that are hardened and comes with a 7" pad.

Price $322.65
KF124233 Chicago Pneumatic Valve-Throttle KF124233 Chicago Pneumatic Valve-Throttle

KF124233 Chicago Pneumatic Valve-Throttle

Discontinued
KF124235 Chicago Pneumatic Stem-Throttle Valve KF124235 Chicago Pneumatic Stem-Throttle Valve

KF124235 Chicago Pneumatic Stem-Throttle Valve

Discontinued
KF124261 Chicago Pneumatic Body-Throttle Valve KF124261 Chicago Pneumatic Body-Throttle Valve

KF124261 Chicago Pneumatic Body-Throttle Valve

Discontinued
KF124262 Chicago Pneumatic Nut-Hex KF124262 Chicago Pneumatic Nut-Hex

KF124262 Chicago Pneumatic Nut-Hex

Discontinued
KF124264 Chicago Pneumatic Screw-Hinge KF124264 Chicago Pneumatic Screw-Hinge

KF124264 Chicago Pneumatic Screw-Hinge

Discontinued
KF124265 Chicago Pneumatic Bracket-Mounting KF124265 Chicago Pneumatic Bracket-Mounting

KF124265 Chicago Pneumatic Bracket-Mounting

Discontinued
KF124267 Chicago Pneumatic Nut-Hex KF124267 Chicago Pneumatic Nut-Hex

KF124267 Chicago Pneumatic Nut-Hex

Discontinued
KF124275 Chicago Pneumatic Housing-Motor KF124275 Chicago Pneumatic Housing-Motor

KF124275 Chicago Pneumatic Housing-Motor

Discontinued
KF124279 Chicago Pneumatic Ring-Ret KF124279 Chicago Pneumatic Ring-Ret

KF124279 Chicago Pneumatic Ring-Ret

Discontinued
KF124280 Chicago Pneumatic Plate-End KF124280 Chicago Pneumatic Plate-End

KF124280 Chicago Pneumatic Plate-End

Discontinued
KF124281 Chicago Pneumatic Dowel-Liner KF124281 Chicago Pneumatic Dowel-Liner

KF124281 Chicago Pneumatic Dowel-Liner

Price $3.86
KF124283 Chicago Pneumatic Body-Rotor KF124283 Chicago Pneumatic Body-Rotor

KF124283 Chicago Pneumatic Body-Rotor

Discontinued
KF124286 Chicago Pneumatic Key-Rotor KF124286 Chicago Pneumatic Key-Rotor

KF124286 Chicago Pneumatic Key-Rotor

Discontinued
KF124291 Chicago Pneumatic Washer-Flat KF124291 Chicago Pneumatic Washer-Flat

KF124291 Chicago Pneumatic Washer-Flat

Discontinued
KF124296 Chicago Pneumatic Housing-Drive KF124296 Chicago Pneumatic Housing-Drive

KF124296 Chicago Pneumatic Housing-Drive

Discontinued
KF124297 Chicago Pneumatic Gasket-Housing KF124297 Chicago Pneumatic Gasket-Housing

KF124297 Chicago Pneumatic Gasket-Housing

Discontinued
KF124298 Chicago Pneumatic Screw-Hxskthd 10-24 KF124298 Chicago Pneumatic Screw-Hxskthd 10-24

KF124298 Chicago Pneumatic Screw-Hxskthd 10-24

Price $3.86
KF125347 Chicago Pneumatic Washer-Spring KF125347 Chicago Pneumatic Washer-Spring

KF125347 Chicago Pneumatic Washer-Spring

Discontinued
KF127279 Chicago Pneumatic Spacer KF127279 Chicago Pneumatic Spacer

KF127279 Chicago Pneumatic Spacer

Discontinued
KF127281 Chicago Pneumatic Shaft-Rotor KF127281 Chicago Pneumatic Shaft-Rotor

KF127281 Chicago Pneumatic Shaft-Rotor

Discontinued
KF127298 Chicago Pneumatic Lock-Spindle KF127298 Chicago Pneumatic Lock-Spindle

KF127298 Chicago Pneumatic Lock-Spindle

Discontinued
KF127299 Chicago Pneumatic Hub-Orbital KF127299 Chicago Pneumatic Hub-Orbital

KF127299 Chicago Pneumatic Hub-Orbital

Discontinued
KF129003 Chicago Pneumatic Bushing-Reducing KF129003 Chicago Pneumatic Bushing-Reducing

KF129003 Chicago Pneumatic Bushing-Reducing

Discontinued
KF129004 Chicago Pneumatic Tubing-Shrink KF129004 Chicago Pneumatic Tubing-Shrink

KF129004 Chicago Pneumatic Tubing-Shrink

Discontinued
KF129006 Chicago Pneumatic Valve-Speed Reg KF129006 Chicago Pneumatic Valve-Speed Reg

KF129006 Chicago Pneumatic Valve-Speed Reg

Discontinued
KF132237 Chicago Pneumatic Kit Tune Up CP0864 KF132237 Chicago Pneumatic Kit Tune Up CP0864

KF132237 Chicago Pneumatic Kit Tune Up CP0864

Discontinued See Individual Parts
KF137768 Chicago Pneumatic Ring-Retaining KF137768 Chicago Pneumatic Ring-Retaining

KF137768 Chicago Pneumatic Ring-Retaining

Discontinued
KF138241 Chicago Pneumatic Rotor Blade Set KF138241 Chicago Pneumatic Rotor Blade Set

KF138241 Chicago Pneumatic Rotor Blade Set For CP864 / CP777 / CP766 Units

Price $14.85
KF139516 Chicago Pneumatic Spindle Assy KF139516 Chicago Pneumatic Spindle Assy

KF139516 Chicago Pneumatic Spindle Assy

Discontinued
KF140612 Chicago Pneumatic Lever-Lockoff (Comp) KF140612 Chicago Pneumatic Lever-Lockoff (Comp)

KF140612 Chicago Pneumatic Lever-Lockoff (Comp)

Discontinued
P006600 Chicago Pneumatic Lockwasher-5/16" P006600 Chicago Pneumatic Lockwasher-5/16"

P006600 Chicago Pneumatic Lockwasher-5/16"

Discontinued
P083071 Chicago Pneumatic O-Ring In-011 P083071 Chicago Pneumatic O-Ring In-011

P083071 Chicago Pneumatic O-Ring In-011

Price $2.96
P091352 Chicago Pneumatic Cap Screw P091352 Chicago Pneumatic Cap Screw

P091352 Chicago Pneumatic Cap Screw

Price $5.41
S025055 Chicago Pneumatic Bearing-Ball S025055 Chicago Pneumatic Bearing-Ball

S025055 Chicago Pneumatic Bearing-Ball

Price $24.36
S082840 Chicago Pneumatic Ring-Retaining S082840 Chicago Pneumatic Ring-Retaining

S082840 Chicago Pneumatic Ring-Retaining

Price $3.90
