Chicago Pneumatic CP777 Orbital Sander Repair Parts


Index
No.
Part No. Description No.
Req'd
1 KF129003 Bushing - Air Inlet 1
3 A088212 Spring - Throttle Valve 1
5 KF124233 Valve - Throttle 1
6 KF124235 Stem - Throttle Valve 1
7 P083071 O-Ring (-011) 2
8 A082777 O-Ring (-012) 1
9 KF124261 Body - Throttle Valve 1
13 KF124262 Nut - Hex 1
14 KF140612 Lever - Throttle 1
15 KF124264 Screw - Hinge 1
17 KF124265 Bracket - Mounting 1
18 P006600 Lockwasher 1
19 KF124267 Nut - Hex 1
22 S082840 Ring - Retaining 1
23 C079489 O-Ring (-008) 2
25 KF129006 Valve - Speed Regulator 1
31 KF129004 Cover - Handle (Shrink Tubing) 1
32 KF124275 Housing - Motor
Incl Index No: 31
1
42 KF134269 Cover - Housing 1
54 S025055 Bearing - Ball 4
58 KF124280 Plate - End 1
59 KF135244 Dowel - Liner 1
60 KF135242 Liner
Incl Index No: 59
1
61 KF124283 Body - Rotor 1
62 KF138241 Blade Set - Rotor (4) 1
63 KF140289 Shaft - Rotor 1
65 KF134259 Plate - Lower End 1
70 KF125161 Key 1
124 KF134267 Screw - Thread Tapping 6
125 P105327 Lockwasher 6
126 KF134254 Pad - P.S.A. Sanding 1
127 KF134256 Weight - Balance 1
128 KF140291 Pin - Spiral 1
129 KF134262 Gear - Orbiting 1
130 KF134260 Gear - Internal 1
131 KF134265 Screw - Flat Head 2
132 KF134266 Screw - Flat Head 2
133 KF134253 Washer - Spring 1
134 KF134258 Washer - Retainer 1
135 KF134264 Screw - Flat 1
136 KF134268 O-Ring 1
140 CA144007 Decal - Safety Warning 1
Sort By:
MIL1001-4 Milton Industries Tool Oil 4oz. Flip Top 1001-4 Milton Industries Tool Oil 4oz. Flip Top

Extends life and performance of air tools, lubricators, valves and cylinders. Prevents seizure of air tools and pneumatic equipment. Recommended for tools requiring a 10 weight non-detergent lubricant. Working temperature: 5 F to 350 F.

Price $5.15
2050487813 Chicago Pneumatic Throttle Valve & Spring 2050487813 Chicago Pneumatic Throttle Valve & Spring

2050487813 Chicago Pneumatic Throttle Valve & Spring

Discontinued
8940158455 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease 100Gm Tube 8940158455 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease 100Gm Tube

8940158455 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease 100Gm Tube

Price $29.28
8940158456 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease Cartridge 8940158456 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease Cartridge

8940158456 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease Cartridge

Price $36.54
A082777 Chicago Pneumatic O-Ring In-012 A082777 Chicago Pneumatic O-Ring In-012

A082777 Chicago Pneumatic O-Ring In-012

Price $7.10
A088212 Chicago Pneumatic Throttle Valve Spring A088212 Chicago Pneumatic Throttle Valve Spring

A088212 Chicago Pneumatic Throttle Valve Spring

Discontinued
C079489 Chicago Pneumatic O-Ring In-008 C079489 Chicago Pneumatic O-Ring In-008

C079489 Chicago Pneumatic O-Ring In-008

Price $8.64
C098689 Chicago Pneumatic Push-Type Hand Grease Gun For Flush Fittings C098689 Chicago Pneumatic Push-Type Hand Grease Gun For Flush Fittings

C098689 Chicago Pneumatic Push-Type Hand Grease Gun For Flush Fittings

Price $15.61
CA000046 Chicago Pneumatic Air Tool Oil Protecto Lube 20 Oz. CA000046 Chicago Pneumatic Air Tool Oil Protecto Lube 20 Oz.

CA000046 Chicago Pneumatic Air Tool Oil Protecto Lube 20 Oz. 20 oz. Top-grade product is expertly made in compliance with stringent industry standards to offer a fusion of a well-balanced design and high level of craftsmanship.

Price $8.76
CA144007 Chicago Pneumatic Decal-Safety Warning CA144007 Chicago Pneumatic Decal-Safety Warning

CA144007 Chicago Pneumatic Decal-Safety Warning

Price $3.44
CA149661 Chicago Pneumatic Oil Protecto Lube 4 Oz. CA149661 Chicago Pneumatic Oil Protecto Lube 4 Oz.

CA149661 Chicago Pneumatic Oil Protecto Lube 4 Oz.

Price $4.86
CP7265S Chicago Pneumatic 7" Vertical Sander CP7265S Chicago Pneumatic 7" Vertical Sander

CP7265S 7" Vertical Sander - This heavy duty vertical sander comes with features like: a 1 horse power motor, muffled and vented exhaust away from work surface, 7" pad and a powerful motor with speed control switch. It is ideally suited for roughing in body filler, welds, smoothing pain, rust and stone removal.

Price $341.13
KF124233 Chicago Pneumatic Valve-Throttle KF124233 Chicago Pneumatic Valve-Throttle

KF124233 Chicago Pneumatic Valve-Throttle

Discontinued
KF124235 Chicago Pneumatic Stem-Throttle Valve KF124235 Chicago Pneumatic Stem-Throttle Valve

KF124235 Chicago Pneumatic Stem-Throttle Valve

Discontinued
KF124261 Chicago Pneumatic Body-Throttle Valve KF124261 Chicago Pneumatic Body-Throttle Valve

KF124261 Chicago Pneumatic Body-Throttle Valve

Discontinued
KF124262 Chicago Pneumatic Nut-Hex KF124262 Chicago Pneumatic Nut-Hex

KF124262 Chicago Pneumatic Nut-Hex

Discontinued
KF124264 Chicago Pneumatic Screw-Hinge KF124264 Chicago Pneumatic Screw-Hinge

KF124264 Chicago Pneumatic Screw-Hinge

Discontinued
KF124265 Chicago Pneumatic Bracket-Mounting KF124265 Chicago Pneumatic Bracket-Mounting

KF124265 Chicago Pneumatic Bracket-Mounting

Discontinued
KF124267 Chicago Pneumatic Nut-Hex KF124267 Chicago Pneumatic Nut-Hex

KF124267 Chicago Pneumatic Nut-Hex

Discontinued
KF124275 Chicago Pneumatic Housing-Motor KF124275 Chicago Pneumatic Housing-Motor

KF124275 Chicago Pneumatic Housing-Motor

Discontinued
KF124280 Chicago Pneumatic Plate-End KF124280 Chicago Pneumatic Plate-End

KF124280 Chicago Pneumatic Plate-End

Discontinued
KF124283 Chicago Pneumatic Body-Rotor KF124283 Chicago Pneumatic Body-Rotor

KF124283 Chicago Pneumatic Body-Rotor

Discontinued
KF125161 Chicago Pneumatic Key KF125161 Chicago Pneumatic Key

KF125161 Chicago Pneumatic Key

Price $7.17
KF129003 Chicago Pneumatic Bushing-Reducing KF129003 Chicago Pneumatic Bushing-Reducing

KF129003 Chicago Pneumatic Bushing-Reducing

Discontinued
KF129004 Chicago Pneumatic Tubing-Shrink KF129004 Chicago Pneumatic Tubing-Shrink

KF129004 Chicago Pneumatic Tubing-Shrink

Discontinued
KF129006 Chicago Pneumatic Valve-Speed Reg KF129006 Chicago Pneumatic Valve-Speed Reg

KF129006 Chicago Pneumatic Valve-Speed Reg

Discontinued
KF134253 Chicago Pneumatic Washer-Spring KF134253 Chicago Pneumatic Washer-Spring

KF134253 Chicago Pneumatic Washer-Spring

Discontinued
KF134256 Chicago Pneumatic Weight-Balance KF134256 Chicago Pneumatic Weight-Balance

KF134256 Chicago Pneumatic Weight-Balance

Discontinued
KF134259 Chicago Pneumatic Plate-Lower End KF134259 Chicago Pneumatic Plate-Lower End

KF134259 Chicago Pneumatic Plate-Lower End

Price $20.64
KF134262 Chicago Pneumatic Gear-Orbiting KF134262 Chicago Pneumatic Gear-Orbiting

KF134262 Chicago Pneumatic Gear-Orbiting

Price $33.69
KF134264 Chicago Pneumatic Scrw-Flhxskthd 8-32 KF134264 Chicago Pneumatic Scrw-Flhxskthd 8-32

KF134264 Chicago Pneumatic Scrw-Flhxskthd 8-32

Price $8.67
KF134265 Chicago Pneumatic Scrw-Flhxskthd 10-24 KF134265 Chicago Pneumatic Scrw-Flhxskthd 10-24

KF134265 Chicago Pneumatic Scrw-Flhxskthd 10-24

Discontinued
KF134266 Chicago Pneumatic Scrw-Flhxskthd 10-24 KF134266 Chicago Pneumatic Scrw-Flhxskthd 10-24

KF134266 Chicago Pneumatic Scrw-Flhxskthd 10-24

Price $7.11
KF134267 Chicago Pneumatic Screw-Tapping KF134267 Chicago Pneumatic Screw-Tapping

KF134267 Chicago Pneumatic Screw-Tapping

Price $5.37
KF134268 Chicago Pneumatic O-Ringin-137 KF134268 Chicago Pneumatic O-Ringin-137

KF134268 Chicago Pneumatic O-Ringin-137

Price $7.11
KF134269 Chicago Pneumatic Cover-Housing KF134269 Chicago Pneumatic Cover-Housing

KF134269 Chicago Pneumatic Cover-Housing

Discontinued
KF135242 Chicago Pneumatic Liner KF135242 Chicago Pneumatic Liner

KF135242 Chicago Pneumatic Liner

Discontinued
KF135244 Chicago Pneumatic Pin KF135244 Chicago Pneumatic Pin

KF135244 Chicago Pneumatic Pin

Price $3.90
KF138241 Chicago Pneumatic Rotor Blade Set KF138241 Chicago Pneumatic Rotor Blade Set

KF138241 Chicago Pneumatic Rotor Blade Set For CP864 / CP777 / CP766 Units

Price $14.85
KF140289 Chicago Pneumatic Shaft-Rotor KF140289 Chicago Pneumatic Shaft-Rotor

KF140289 Chicago Pneumatic Shaft-Rotor

Discontinued
KF140291 Chicago Pneumatic Pin-Spirol(4mmx22) KF140291 Chicago Pneumatic Pin-Spirol(4mmx22)

KF140291 Chicago Pneumatic Pin-Spirol(4mmx22)

Discontinued
KF140612 Chicago Pneumatic Lever-Lockoff (Comp) KF140612 Chicago Pneumatic Lever-Lockoff (Comp)

KF140612 Chicago Pneumatic Lever-Lockoff (Comp)

Discontinued
P006600 Chicago Pneumatic Lockwasher-5/16" P006600 Chicago Pneumatic Lockwasher-5/16"

P006600 Chicago Pneumatic Lockwasher-5/16"

Discontinued
P083071 Chicago Pneumatic O-Ring In-011 P083071 Chicago Pneumatic O-Ring In-011

P083071 Chicago Pneumatic O-Ring In-011

Price $2.96
P105327 Chicago Pneumatic Lockwasher-#10 P105327 Chicago Pneumatic Lockwasher-#10

P105327 Chicago Pneumatic Lockwasher-#10

Discontinued
S025055 Chicago Pneumatic Bearing-Ball S025055 Chicago Pneumatic Bearing-Ball

S025055 Chicago Pneumatic Bearing-Ball

Price $24.36
S082840 Chicago Pneumatic Ring-Retaining S082840 Chicago Pneumatic Ring-Retaining

S082840 Chicago Pneumatic Ring-Retaining

Price $3.90
