| Index No. | Part No. | Description | No. Req'd |
| 1 | CA145052 | Head - Cylinder | 1 |
| 2 | CA145053 | Pin - Dowel | 2 |
| 3 | CA145054 | Bumper | 1 |
| 4 | CA145055 | Piston (Incl: 3) | 1 |
| 5 | CA145056 | Gasket | 1 |
| 6 | CA145057 | Cylinder | 1 |
| 7 | CA145058 | Pin - Dowel | 2 |
| 8 | CA145059 | Valve | 1 |
| 9 | CA145060 | Valve Assembly (Incl: 8) | 1 |
| 10 | CA145061 | Seat - Valve | 1 |
| 11 | CA145062 | Body - Throttle Valve | 1 |
| 12 | CA145063 | O-Ring | 1 |
| 13 | CA145064 | Stem - Throttle Valve | 1 |
| 14 | CA145065 | O-Ring | 1 |
| 15 | CA145066 | Spring - Throttle Valve | 1 |
| 16 | CA145067 | O-Ring | 2 |
| 17 | CA145068 | Cap - Throttle Valve | 1 |
| 18 | CA145069 | O-Ring | 1 |
| 19 | 8940158360 | Housing - Motor | 1 |
| 20 | 8940158365 | Bushing - Air Inlet Assembly | 1 |
| 21 | CA145072 | Guide - Blade Holder | 1 |
| 22 | CA145073 | Screw | 2 |
| 23 | CA145074 | Holder - Blade | 1 |
| 24 | CA145075 | Screw - Set | 3 |
| 25 | CA145076 | Screw - Set | 1 |
| 26 | CA145077 | Cover - Holder | 1 |
| 27 | 8940158361 | Guard - Blade | 1 |
| 28 | 8940158362 | Gasket - Front | 1 |
| 29 | CA145080 | Wrench - Hex | 1 |
| 30 | CA145081 | Lever - Throttle | 1 |
| 31 | CA145082 | Pin - Roll | 1 |
| 32 | 8940158366 | Muffler Cap | 1 |
| 33 | 8940158367 | Muffler | 1 |
| 34 | CA146719 | Blade - Saw (18T) (Pack of 5) | - |
| 34 | CA146720 | Blade - Saw (24T) (Pack of 5) | - |
| 34 | CA146721 | Blade - Saw (32T) (Pack of 5) | - |
| - | CA144007 | Decal - Safety Warning (not shown) | 1 |
