You are here: Home > Battery Charger Parts > Associated Battery Charger Parts Listing By Model > 6127 Associated Battery Charger Parts List
There are 3 vintages of the 6127.
6127, 6127A and then 6127XL.
No information on the 1st generation of 6127 or the production start date of the 6127A.
6127A's stopped production 10/96 & have s/n range of 009611-010487.
The new 6127 started production in 11/96 with s/n starting at zero again.

610091 Wheels w/ Nuts (2)
610072 Side Panels (2)
610469 Back
610473 Top; Battery Cabinet
610475 Front; screened
610052 Axle w/Nuts
610516 Circuit Board (diagonal configuration)
610617 Circuit Board (horizontal configuration)
605206 AC Cord (16/3)
610474 Top; Charger Cabinet
610515 Transformer
610047 Front Leg
610095 Battery Strap
605207 DC Cable Set (includes stop/go assy)
605213 Handle
610593 Battery Tray Assy; (includes bat tray & strap)
MAINTENANCE INSTRUCTIONS
Worn clamps should be replaced. Worn parts can lead to poor connections and present a safety hazard. See parts list for part number of DC Cable Set. Any Maintenance or repair of this unit that involves disassembly of the cabinet should be done only by a qualified serviceman. Incorrect reassembly may result in a risk of electric shock when the unit is subsequently used.
Sort By:
Page of 1
020-0076 Associated Chrome Handle Screws (Each) 020-0076 Associated Chrome Handle Screws (Each)

020-0076 Associated Chrome Handle Screws (Each)

Price $1.54
605206 Associated A/C Cord 16-3 605206 Associated A/C Cord 16-3

605206 Associated A/C Cord 16-3

Discontinued
605207 Associated DC Cable Set DISC SEE 611074 605207 Associated DC Cable Set

Associated 605207 DC Cable Set DISC SEE 611074

Discontinued See 611074
605213 Associated Chrome Handle 605213 Associated Chrome Handle

Chrome Handle with screws and insulated clamp bar.

Price $52.11
610091 Associated Wheels With Nuts 610091 Associated Wheels With Nuts

610091 Associated Wheels With Nuts

Discontinued See 610553
610515 Associated Transformer 6127A 610515 Associated Transformer 6127A

Transformer 6127A Serial Number 5477 Or Greater & 7127PG Serial Number 972 Or Greater

Price $178.21
610516 Associated Circuit Board Diagonal Configuration 610516 Associated Circuit Board Diagonal Configuration

CIRCUIT BOARD DIAGONAL CONFIGURATION

Price $413.75
610517 Associated Clamp Bar 7" 610517 Associated Clamp Bar 7"

610517 Associated Clamp Bar 7"

Price $7.58
610593 Associated Tray & Strap Kit 6127A & B 610593 Associated Tray & Strap Kit 6127A & B

610593 Associated Tray & Strap Kit 6127A & B

Price $28.68
610617 Associated Circuit Board Horizontal Configuration 610617 Associated Circuit Board Horizontal Configuration

610617 Associated Circuit Board Horizontal Configuration

Price $130.34
610753 Associated Chrome Handle 610753 Associated Chrome Handle

610753 Associated Chrome Handle

Discontinued See 605213
611074 Associated DC Cable Assembly 8' (4 AWG) 611074 Associated DC Cable Assembly 8' (4 AWG)

Associated DC Cable Assembly, with 500 amp, fully insulated, "Flex-Spring" clamps. 8' (4 AWG)

Price $163.90


6127 Associated Battery Charger Parts List
