216-041-666 115 Volt Fan Motor Open Frame Design
|
|
|
115 Volt Fan Motor Open Frame Design. Clock Wise Shaft End, mechanically reversible for universal applications.
|
|
|
|
|
|
|
|
|
|
238-006-666 Clamp Kit 8 Foot 6 Gauge Parrot Jaw
|
|
|
8' 6AWG Welding Wire Lead Set with heavy duty polished clamps featuring coated clamp handles. a 50 lb. Jaw Strength provides positive connections and color coded wires make for easy identification. These even have molded strain relief built on the cables. Ring terminal connections make installation a snap.
|
|
|
|
|
|
|
|
|
|
238-260-666 Century Positive Cable & Clamp Assembly 6ga 106"
|
|
|
238-260-666 Century Positive Cable & Clamp Assembly 6ga 106" for Century / Solar battery chargers. Universal Style for other chargers. Booster Clamp features 6 Gauge solid copper wire, dual power jaws for better conductivity with a braided internal power crossover strap (distributes full power to both jaws), heavy duty construction for durability and long life.
|
|
|
|
|
|
|
|
|
|
238-261-666 Century Negative Cable & Clamp Assembly 6ga 106"
|
|
|
238-261-666 Century Negative Cable & Clamp Assembly 6ga 106" for Century / Solar battery chargers. Universal Style for other chargers. Booster Clamp features 6 Gauge solid copper wire, dual power jaws for better conductivity with a braided internal power crossover strap (distributes full power to both jaws), heavy duty construction for durability and long life.
|
|
|
|
|
|
|
|
|
|
246-041-666 Selector Knob
|
|
|
246-041-666 Selector Knob
|
|
|
|
|
|
|
|
|
|
246-243-000 Circuit Breaker 12 Volt 50 Amp (578800-050)
|
|
|
246-243-000 Circuit Breaker 12 Volt 50 Amp (578800-050). Universal Breaker replaces many older unit parts.
|
|
|
|
|
|
|
|
|
|
246-386-000 Dual Circuit Breaker W/Tabs 50/100 Amp
|
|
|
Battery Charger Circuit Breaker. Dual 12 Volt 50 Amp, Single Pole Thermal Type Breaker (Paired), Bracket Type Mounting, 10-32 Studs.
|
|
|
|
|
|
|
|
|
|
246-408-000 6 Position Rotary Selector Switch (No Knob)
|
|
Discontinued See 246-408-666
|
|
|
246-408-000 6 Position Rotary Selector Switch (No Knob). This switch has been modified from the original metal stem design to a plastic stem and the pin locations have changed. Switch should be wired number to number not by tab location.
|
|
|
|
|
|
|
|
|
|
246-408-666 Rotary Selector Switch 6 Position With Knob
|
|
|
246-408-666 Rotary Selector Switch 6 Position With Knob. This switch has been modified from the original metal stem design to a plastic stem and the pin locations have changed. Switch should be wired number to number not by tab location. Includes instructions.
|
|
|
|
|
|
|
|
|
|
247-074-666 Ammeter Horizontal 0-60 Amp Range W/Start
|
|
|
Ammeter Horizontal 0-60 AMP features easy snap-in installation. Green Red Charge Rate face. 0-60 Amp range and bolt through induction pick-up for greater accuracy.
|
|
|
|
|
|
|
|
|
|
247-132-000 Ammeter Horizontal 0-60 Amp Range
|
|
Discontinued See 247-147-000
|
|
|
Ammeter Horizontal 0-60 AMP features easy snap-in installation. Green Red Charge Rate face. 0-60 Amp range and wire through induction pick-up for greater accuracy. Replaces old style bolt through meters.
|
|
|
|
|
|
|
|
|
|
247-147-000 Ammeter Horizontal 0-60 Amp
|
|
|
247-147-000 Ammeter Horizontal 0-60 Amp features easy snap-in installation. Green Red Charge Rate face. 0-60 Amp range and wire through induction pick-up for greater accuracy. Replaces old style bolt through meters.
|
|
|
|
|
|
|
|
|
|
|
247-158-666 Ammeter Horizontal 0-60 Amp Range
|
|
Discontinued See 247-132-000
|
|
|
Ammeter Horizontal 0-60 AMP features easy snap-in installation. Green Red Charge Rate face. 0-60 Amp range and wire through induction pick-up for greater accuracy. Replaces old style bolt through meters.
|
|
|
|
|
|
|
|
|
|
249-066-666 Booster Clamps Positive & Negative
|
|
|
Clamps Positive & Negative. Screw Type Connection for ring terminal cables to anchor wire for solderless connection. Dual Hot Jaws for better power distribution. Includes Phillips anchor screws. Does not include hardware for cables, (ring terminals, solder etc...).
|
|
|
|
|
|
|
|
|
|
249-093-900 Black Negative Booster Clamp
|
|
|
Black Negative Booster Clamp features full power jaws (distributes full power to both jaws), heavy duty construction for durability and long life, solid copper jaws for better conductivity, and a braided internal power crossover strap instead of wire for even power to the jaws.
|
|
|
|
|
|
|
|
|
|
249-094-900 Red Positive Booster Clamp
|
|
|
Red Positive Booster Clamp features full power jaws (distributes full power to both jaws), heavy duty construction for durability and long life, solid copper jaws for better conductivity, and a braided internal power crossover strap instead of wire for even power to the jaws.
|
|
|
|
|
|
|
|
|
|
316-014-000 Fan Blade 6" 4 Blade CW
|
|
|
316-014-000 Fan Blade 6" 4 Blade CW
|
|
|
|
|
|
|
|
|
|
412-751-666 Chrome Battery Charger Handle
|
|
|
412-751-666 Chrome Battery Charger Handle. Replaces 442-020-166 and other older Century / Solar Handles
|
|
|
|
|
|
|
|
|
|
442-020-166 Century Battery Charger Handle
|
|
|
442-020-166 Century Battery Charger Handle. Flat side black painted finish.
|
|
|
|
|
|
|
|
|
|
51-236 Goodall 250 Amp Heatsink Rectifier
|
|
|
51-236 Goodall 250 Amp Heatsink Rectifier Kit 60 Amp Continuous Duty, 12 Diode Daisy Wheel Design. Extra Long center studs for thick transformer lead wires.
|
|
|
|
|
|
|
|
|
|
512-001-000 Rectifier Insulator Standoff (New Style)
|
|
|
512-001-000 Rectifier Insulator Standoff (New Style). Connects to the back wall of the charger chassis to provide a mount for the rectifier.
|
|
|
|
|
|
|
|
|
|
512-127-000 Rectifier Insulator Standoff
|
|
|
512-127-000 Rectifier Insulator Standoff. Connects to the back wall of the charger chassis to provide a mount for the rectifier.
|
|
|
|
|
|
|
|
|
|
865-926-666 Century Rectifier 250 Amp 12 Diode
|
|
|
865-926-666 Century Rectifier 250 Amp 12 Diode 60 Amp Continuous Duty. Fits Most Older Century & Solar Models with thin wire connections only. If your Transformer taps are heavy duty wires see 51-236 for rectifier with Long Bolt Connections.
|
|
|
|
