BCH6006 Mac Tools Battery Charger Parts List

BCH6006 MAC Tools Battery Charger Parts List
BCH6006 MAC Tools Battery Charger Parts List
1. Front leg 605671 15.
Clamps (1 pair, includes jaws) 6202
2. Wheels w/nuts (2) 611157 16.
Jaw kit (repairs 1 clamp)
610970
3. Axle w/nuts 610052 17.
Front Panel
611085
4. Transformer
610862 18.
Right-side Panel (front view) 611032
5. Rectifier
610850 19.
Back Panel
610977
6. Fan Blade 610189 20.
Pointer Knob
603147
7. Fan Motor
610190 21.
AC Circuit Breaker 610397
8. Timer w/knob 611245 22.
Clamp Bar
610517
9. Amps Charge Meter
605204 23.
Base
610054
10. DC Circuit Breaker (1) 610536 Not Shown Left-side Panel (front view)
611031
11. DC Cable Set
611084 Not Shown Stop Go Light For Clamps
605579
12. Handle
605213 Not Shown Top Panel (front view) 611011
13. AC Cord 611248


14. Switch w/knob 611083



MAINTENANCE INSTRUCTIONS
Worn clamps and jaws should be replaced. Worn parts can lead to poor connections and present a safety hazard. See parts list for part number of jaw and clamp kits. Any Maintenance or repair of this unit that involves disassembly of the cabinet should be done only by a qualified serviceman. Incorrect reassembly may result in a risk of electric shock when the unit is subsequently used.
Sort By:
Page of 1
020-0076 Associated Chrome Handle Screws (Each)
020-0076 Associated Chrome Handle Screws (Each)
Price $1.40

020-0076 Associated Chrome Handle Screws (Each)
600121 Associated Meter Cover
600121 Associated Meter Cover
Price $9.70

Clear Acrylic Lens Replaces Cover For 605204 Meter And Others
6006 Associated 70/65/30/280 Amp 6/12/24 Volt Automotive Battery Charger W/Start
6006 Associated 70/65/30/280 Amp 6/12/24 Volt Automotive Battery Charger W/Start
Price $514.50

Made In The USAThe 6006 Associated battery charger is one of the highest performance fleet car battery charger on the market, Charges 6, 12 and 24 volt batteries. Heavy-duty transformer, patented "Sub-Sil" multi diode rectifiers, longer AC cord and DC leads for higher performance. "Safe In Any Weather".
603147 Associated Pointer Knob
603147 Associated Pointer Knob
Price $12.34

Pointer Knob. Half Round Shaft.
605204 Associated Ammeter 0-100 Amp Range W/ Boost
605204 Associated Ammeter 0-100 Amp Range W/ Boost
Price $28.40

Associated 605204 Ammeter 0-100 Amp Range w/ Boost. Includes Sealing Gasket, Mounting Template and mounting hardware. (Same as 614-77982 Marquette)
605213 Associated Chrome Handle
605213 Associated Chrome Handle
Price $50.43

Chrome Handle with screws and insulated clamp bar.
605671 Associated Front Leg With Screws
605671 Associated Front Leg With Screws
Price $30.85

Front Leg With Screws
605672 Associated Wheel Kit With Nuts (Set Of Two Plastic)
605672 Associated Wheel Kit With Nuts (Set Of Two 6" Plastic)
Price $34.92

605672 Associated Wheel Kit With Nuts (Set Of Two 6" Plastic)
610043 Associated 3/8 Axle Cap (Each)
610043 Associated 3/8 Axle Cap (Each)
Price $2.18

610043 Associated 3/8 Axle Cap (Each)
610052 Associated Axle With Nuts
610052 Associated Axle With Nuts
Price $29.69

610052 Associated Axle With Nuts. Axle 3/8" O.D. x 15-3/4" Long
610189 Fan Blade Kit 6" 4 Wing
610189 Fan Blade Kit 6" 4 Wing
Price $13.92

610189 Fan Blade Kit 6" 4 Wing, two blades with the same diameter, rotation, pitch and wings but differing shaft diameter for older units.
610190 Associated Fan Motor Installation Kit 115 Volt
610190 Associated Fan Motor Installation Kit 115 Volt
Price $60.04

Universal Fan Motor Installation Kit includes everything needed to install on virtually any unit. Comes complete with a 115v. skeleton frame motor (reversible), equipped with 1/4" spade terminals for electrical connections, a fan blade, a set of 1/4" female spade terminal adapter leads, 1/4" Crimp-on female spades for alternate hook up, 2 sets of pin terminals for molex plug installation and 2 wire nuts.
610389 Associated 90 Minute Mechanical Timer w/ Hold Retro-fit Kit
610389 Associated 90 Minute Mechanical Timer w/ Hold Retro-fit Kit
Discontinued

This kit provides everything needed to replace older obsolete electrical driven timers with a new spring wound mechanical timer. The kit includes Knob, wiring and electrical connections, wire ties, spade terminals for universal applications and instructions.

*If your unit has an Older 90 Minute mechanical timer, use the 611254 retrofit kit to simplify the install. If your unit has an electric 120 minute timer, use the 611245 which is a direct replacement for those units.
610397 Associated AC Circuit Breaker
610397 Associated AC Circuit Breaker
Price $52.26

AC CIRCUIT BREAKER
610517 Associated Clamp Bar 7"
610517 Associated Clamp Bar 7"
Price $7.33

610517 Associated Clamp Bar 7"
610536 Associated 30 Volt DC 110 Amp Circuit Breaker
610536 Associated 30 Volt DC 110 Amp Circuit Breaker
Price $43.28

DC Circuit Breaker Kit
610753 Associated Chrome Handle
610753 Associated Chrome Handle
Discontinued See 605213

610753 Associated Chrome Handle
610850 Associated Rectifier Assy 20 Diode 6x7.76
610850 Associated Rectifier Assy 20 Diode 6x7.76
Price $43.20

Associated 610850 Rectifier Installation Kit. The Highest rated Rectifier on the market, completely assembled, includes mounting hardware and insulators.
610895 Associated Timer W/Knob
610895 Associated 90 Minute Mechanical Timer With Knob
Discontinued See 611254

Mechanically controls charging in timed Mode with manual hold mode. Two Independent Single Pole Single Throw (SPST) Switches rated 15 amperes. 1/4" spade terminals. Timer has Hold Position.
*See 611254 retrofit Timer kit.
610970 Associated 500 Amp Jaw Kit (Repairs One Clamp)
610970 Associated 500 Amp Jaw Kit (Repairs One Clamp)
Price $17.29

500 Amp Jaw Kit (Repairs One Clamp) Heavy Duty Copper construction for long life and high conductance. Includes insulators and screws with acorn nuts.
611083 Associated Rotary Switch W/Knob
611083 Associated Rotary Switch W/Knob
Price $22.13

Associated 611083 Rotary Switch W/Knob
611084 Associated DC Cable Set
611084 Associated DC Cable Set
Price $115.47

DC CABLE SET
611129 Associated Front Panel Slope Bch6006
611129 Associated Front Panel Slope Bch6006
Price $59.34

611129 Associated Front Panel Slope Bch6006
611245 Associated 120 Minute Electronic Timer with Knob
611245 Associated 120 Minute Electronic Timer with Knob
Price $65.55

611245 Associated 120 Minute Electronic Timer with Knob, for use in units with a 120 minute timer already installed. The timer controls battery charging in timed Mode and has a manual hold mode for longer charging cycles. Switch circuits are rated 15 amperes. Termination is designed to accept standard 1/4" spade terminals.

*If your unit has an Older 90 Minute mechanical timer, use the 611254 retrofit kit to simplify the install. If your unit has an electric 120 minute timer, use the 611245 which is a direct replacement for those units.

611254 Associated 120 Minute Electronic Timer with Knob Upgrade Kit
611254 Associated 120 Minute Electronic Timer with Knob Upgrade Kit
Price $74.21

611254 Associated 120 Minute Electronic Timer with Knob, for use in units with a 90 Minute timer already installed. The timer controls battery charging in timed Mode and has a manual hold mode for longer charging cycles. Switch circuits are rated 15 amperes. Termination is designed to accept standard 1/4" spade terminals.

*If your unit has an Older 90 Minute mechanical timer, use the 611254 retrofit kit to simplify the install. If your unit has an electric 120 minute timer, use the 611245 which is a direct replacement for those units.
6200 Associated Side Terminal Adapter Pair
6200 Associated Side Terminal Adapter Pair
Price $6.62

Need side terminal adapters? Model 6200 fits Associated and most other insulated clamps for easier connections. Side terminal adapters clip easily into place inside the clamp rivit and pull out of the way when not in use.
6202 Associated 500 Amp Battery Charger Clamp Heavy Duty Coated (Pair)
6202 Associated 500 Amp Battery Charger Clamp Heavy Duty Coated (Pair)
Price $32.09

Made In U.S.A.Professional quality heavy duty 500 amp replacement clamps for all booster cables. Replace Associated clamps or other manufacturer's products with these professional quality insulated clamps. Clamps incorporate Associated's innovative "Flexi-Spring" for long cable life at the point it bends most. Possibly the best clamp in the industry.
6202 Associated 500 Amp Heavy Duty Coated Clamp  Kit (Pair - Bulk Packaged)
6202 Associated 500 Amp Heavy Duty Coated Clamp Kit (Pair - Bulk Packaged)
Price $28.95

Made In U.S.A.6202 Associated 500 Amp Battery Charger Clamp Heavy Duty Coated for repair shops or fleet maintenance departments and don't need retail packaging, this is your answer. White box units have no POP Sales card attached and are bulk packaged. Professional quality heavy duty 500 amp replacement clamps for all booster cables. Replace Associated clamps or other manufacturer's products with these professional quality insulated clamps. Clamps incorporate Associated's innovative "Flexi-Spring" for long cable life at the point it bends most. Possibly the best clamp in the industry.
6204 Associated 500 Amp Jaw Kit
6204 Associated 500 Amp Jaw Kit (Repairs One Clamp)
Discontinued See 610970

500 Amp Jaw Kit (Repairs One Clamp) Heavy Duty Copper construction for long life and high conductance. Includes insulators and screws with acorn nuts.
