- Continuous Duty High Current Charge.
- 70 AMPS @ 115 VAC
- 100 AMPS @ 230 VAC
- Charges Individual 12V Batteries and 12V Battery Packs Up to 8 Batteries.
- Standard/Flooded or AGM.
- Fast Charge Mode; to 80% State of Charge.
- Full Charge Mode; to 100% Capacity State Of Charge.
- Remaining Charge Time Estimate Displayed.
- Audible Alert when Completed.
- Heavy Duty 2-Gauge Pure Cooper Leads.
- High Current/High Effi ciency.
- Carrying Handle.
- Compatible with the ES-8 Mobile Cart.
- 115 Vac NEMA 5-15P and 230 Vac NEMA 6-15P, 8 ft. Power Cords
Specifications
Battery Voltages ....................................................................... 12 Volt
Charge Sequence ...................... Fast Charge and Full Charge Modes
CCA Range......................................................................... 300 – 1600
LCD .......................................... Backlit 1" x 2.5" 4 line x 16 characters
Maximum Current Output ..........................70 AMPS @ 115 VAC Input; 100 AMPS @ 230 VAC Input
Cooling .............................................................................. Internal Fan
Leads.............................................. 6 Ft., 2 AGW, Fine Strand Copper w/ integrated remote sense wire.
Power Cord......................................................................14 AWG 8 FT
AC Power ................................................................115 VAC 13 AMPS; 230 VAC 7 AMPS
Size ...................................................................14"W X 11.5"D X 9.5H
Weight ........................................................................................24 lbs
