Product Features
- “ON THE RUN” SELF-CLEARING VALVE: No need to turn the unit off when switching from recovery to self-clearing.
- On Board SUCTION AND DISCHARGE gauges
- Small physical size
- Weighs only 10.9 kg (24 lbs)
- COMFORTABLE integrated carrying handle
- 550 psig High-pressure cutout
- BUILT-IN FILTER: located under intake port. No dangling filters to damage.
- FILTER CARTRIDGE can be easily cleaned or replaced
- Integrated Filter Drier with Moisture Indicator
- Suction and Discharge Shut off valves
- HIGH EFFICIENCY rifle-fin condenser/evaporator
- INDESTRUCTIBLE high density polyethylene case
- HEAVY DUTY powder coated aluminum chassis
- MAINTENANCE FREE oil-less compressor
- Suction Oil Separator to collect and measure removed from the mobile A/C system
Specifications- Compressor Type: 1/3 hp reciprocating oil-less
- Recovery Rate: .75 lbs. per minute vapor, 3 lbs. per minute liquid
- Refrigerant Clearing: Manual self clearing valve
- Operation: Single pass recycling
- Evacuation Rating: 28'' hg. After self-evacuation open discharge valve to atmosphere while running unit
- Operating Temp Range: 32ºF to 132ºF
- Weight: 24 lbs. (tank is additional weight)
- Warranty: 1 year parts and labor
|
|
|
|
|
|
|
