554228 Robinair Operating Manual for 34988 Recovery, Recycling, Recharging Unit

554228 Robinair Operating Manual for 34988 Recovery, Recycling, Recharging Unit
Hard Copy & Downloadable PDF

Price $54.95

Product Code: RO554228
Qty:

Description Prop65

Operating Manual for 34988 Recovery, Recycling, Recharging Unit. This is the original factory manual shipped with your unit, original print version "B". Also available as a download PDF file when you check out. You will receive both versions.
Product Features
Table of Contents
Introduction .......................................................... 2
Technical Specifications ........................................2
Keypad Functions .................................................3
Glossary ................................................................3
Menu Functions ....................................................4
Setup
Unpack the Accessory Kit .....................................5
Assemble The Dye Bottle & Oil Bottles.................5
Power Up the Unit .................................................6
Select a Language ..................................................6
Select Operating Units ...........................................7
Set Date & Time ...................................................7
Set Tank Fill Level ................................................7
Add Oil to the Vacuum Pump ................................7
Fill the Internal Storage Vessel ...............................8
Edit Print Header ..................................................9
Operating Instructions
Recover Refrigerant from a Vehicle ......................10
Evacuate the A/C System ......................................11
Flushing the Hoses ...............................................12
Recharge the A/C System ....................................13
Operating Instructions Automatic .....................16
System Flush ..........................................................17
Maintenance
General ................................................................19
Electrical Protection .............................................19
Manually Fill the Internal Storage Vessel (ISV) ...19
Replace the Filter-Drier ........................................20
Scale Calibration Check .......................................21
Change Vacuum Pump Oil ...................................22
Adjust Tank Fill Level ..........................................23
Check for Leaks ..................................................23
Replace Printer Paper ..........................................23
Edit Print Header .................................................24
Replacement Parts ...............................................24
Spanish Manual ..............................................................25
French Manual ...............................................................51
Safety Precautions .................................Inside Front Cover
Warranty ...............................................Inside Back Cover
