  15548 Robinair Pump Assembly Less Motor For 15600 Vacuum Pump

15548 Robinair Pump Assembly Less Motor For 15600 Vacuum Pump

Price $241.08

Product Code: RO15548
Qty:

Description

Forward Pumping section for 6 CFM Vacuum Pumps. Includes Pump, Iso Valve Installed, drain fitting and oil fill cap. For model 15600. Robinair Vacuum Pumps are engineered specifically to meet your A/C maintenance needs and to give you trouble-free operation. Take advantage of our years of experience and know-how developing pumps to help you do your job faster and better.
Designed for use on A/C-R systems using CFCs, HCFCs, and HFCs in conjunction with mineral oil, ester oil, alkylbenzene oil and PAG oil as lubricants. Do not use with ammonia or lithium bromide systems; not for use with flammable refrigerants.
Product Features
  • Iso-Valve Isolates the pump from the system with just a quarter-turn
  • Gas Ballast Moisture laden air passing through the pump mixes with relatively dry air to such a degree that compression does not cause condensation.
  • Two-stage Design Cleans the system more thoroughly than a single-stage pump; the second stage starts pumping at a lower pressure so you can pull a deeper, ultimate vacuum
  • Oil Drain Valve Positioned at the bottom of the oil reservoir and angled for faster, more complete draining
  • Oil Fill Port Makes adding oil simple since the port is accessible from the front or either side. The sight glass on the front of the pump shows you when enough oil has been added
  • Offset Rotary Vanes Our proven design builds a powerful compression within the pumping chamber to reduce system pressure and vaporize moisture so it can be exhausted along with air
  • Die-Cast Aluminum Housing Cast aluminum housings make the pumps lightweight but durable

Free Air Displacement:

6 CFM

Number of Stages:

Two

Factory Micron Rating:

20 microns

Intake Fitting:

1/4" MFL and 1/2" MFL Tee

Oil Capacity:

13 oz.
